Steel Detailing
About This Service
Professional steel detailing using SDS2 and BIM software.
VP & Associates has been providing structural and miscellaneous steel detailing since 2007. We’ve detailed projects as large as 1,500 tons using SDS2, providing all CNC data required for fabrication.
Our detailing services include:
- SDS2 detailing
- BIM steel modeling
- Erection drawings
- Fabrication drawings
- Connection calculations
- Material takeoffs and bills
We sign and seal shop drawings including miscellaneous metals. Our team communicates directly with the Engineer of Record to resolve loading conditions.
Why Choose VP Associates?
- Licensed Florida engineers
- Code-compliant designs
- Fast turnaround times
- Buildable solutions
- Cost-effective optimization
How This Service Works
Our proven process from consultation to support
Step 1: Consultation
Initial project review and scope discussion
Step 2: Design
Structural analysis and calculation preparation
Step 3: Review
Plan preparation and permitting support
Step 4: Support
Construction administration and field services
Related Services
Explore other services that may fit your project needs
Next step
Ready to Discuss Your Project?
Our team is ready to provide expert steel detailing services
Or email info@vp-associates.com
